DC-DC Ultra slim Industrial DIN rail converter; Input 16.8-33.6Vdc; Single Output 12Vdc at 10A
Properties
- Series: DDR-120
- Brand: Mean Well
- Dimensions LxWxH (mm): 147x58x134 mm
- Warranty: 36 Months Bring-In
- Gross weight: 590
- Type: DC-DC
- Form factor: DIN rail
- Mounting method: DIN-rail mount
- Min. output voltages (V): 12
- Max. output voltage (V): 12
- Number of output voltages: 1
- Max output power (W): 120
- Input voltage (V): 16.8 - 33.6
- Min. input voltage: 16.8
- Max. input voltage (V): 33.6
- Max. output current (A): 10
- Number of output currents: 1
- IP rating: No IP assigned
- LED driver: No
- Dimming technologies: No Dimming
- Control signals: No control signals
- Carbon footprint (kgCO2e/pcs): 9.84
