DC-DC Ultra slim Industrial DIN rail converter; Input 16.8-33.6Vdc; Single Output 48Vdc at 5A
Properties
- Series: DDR-240
- Brand: Mean Well
- Dimensions LxWxH (mm): 113.5x40x125.2 mm
- Warranty: 36 Months Bring-In
- Gross weight: 760
- Type: DC-DC
- Form factor: DIN rail
- Mounting method: DIN-rail mount
- Min. output voltages (V): 48
- Max. output voltage (V): 48
- Number of output voltages: 1
- Max output power (W): 240
- Input voltage (V): 16.8 - 33.6
- Min. input voltage: 16.8
- Max. input voltage (V): 33.6
- Max. output current (A): 5
- Number of output currents: 1
- IP rating: No IP assigned
- LED driver: No
- Dimming technologies: No Dimming
- Control signals: DC OK, ON/OFF, Over Temperature
- Carbon footprint (kgCO2e/pcs): 13.65
