AC-DC Single output enclosed power supply; AC input select switch; Output 24Vdc at 6.5A; Up to 5G vibration; 1U low profile
Properties
- Series: LRS-150
- Brand: Mean Well
- Dimensions LxWxH (mm): 168x104x36 mm
- Warranty: 36 Months Bring-In
- Gross weight: 420
- Type: AC-DC
- Form factor: Enclosed
- Mounting method: Chasis mount
- Min. output voltages (V): 24
- Max. output voltage (V): 24
- Number of output voltages: 1
- Max output power (W): 150
- Input voltage (V): 85 - 132, 170 - 264
- Min. input voltage: 85
- Max. input voltage (V): 264
- Max. output current (A): 6.5
- Number of output currents: 1
- IP rating: No IP assigned
- LED driver: No
- Dimming technologies: No Dimming
- Control signals: No control signals
- Carbon footprint (kgCO2e/pcs): 6.21
